Introduction

TD75 fixed type belt conveyor is used to convey bulk material or packed product, it can work single or several unit or work together with other conveyors form horizontal conveying system or inclined system. Its working temperature is between -25℃～40℃, it requires conveying material should not exceed 60℃, heat-resistance belt can convey material below 120 ℃。If material temperature higher than this, belt conveyor is not suitable. It should use oil resistance, or acid and bases proof rubber belt or plastic belt when it convey grease material or material has property of acid, bases etc.

Application of Fixed Belt Conveyor:

Metallurgy, mining, coal, chemical engineering industries.

Features

1. Wide range of conveying material, it can convey wet, dry, powdery or lump material or packed product.

2. Big conveying capacity and long conveying distance.

3. It even can realize multipoint load material and discharge.

4. Stable running, small noise.

5. Simple structure, reliable working, easy operation, easy installation and maintenance.

Technical Parameter

Model	Rubber Belt			Conveying Length	Diameter of Driving Drum	Capacity	Power (kW)	Weight
Model	Width(mm)	Speed (m/s)	Inclined(°)	(m)	(mm)	(t/h)	(t/h)	(t)
TD-500	500	0.8~2.5	0~20	2~240	500、630	40~232	1.5~30	3.93
TD-650	650	0.8~2.5	0~20	2~240	500、630	67~391	1.5~45	5.1
TD-800	800	0.8~3.15	0~20	2~240	500、630	118~824	2.2~75	7.2
TD-1000	1000	1~3.15	0~20	2~240	500、630、800	230~1233	4~100	9.7
