China is the world’s largest producer and consumer of aluminum. Secondary aluminum ash is the waste of primary aluminum ash extracted from metallic aluminum. The main components are alumina (30%-70%) and aluminum nitride (5%-30%). ), metallic aluminum (1%-10%), salts (5%-25%) and other components. The secondary aluminum ash contains toxic and harmful substances such as fluorine and nitrogen, which is the reason why aluminum ash is included in the "National Hazardous Waste List". At present, aluminum electrolysis and aluminum processing enterprises almost all use landfill or storage to dispose of secondary aluminum ash. This approach is not only a waste of resources contained in secondary aluminum ash, but also has the risk of damaging the surrounding ecological environment.



The aluminum slag recycling and processing equipment and technology are relatively backward. Many small companies use manual sorting and cooling to sell directly to the outside world. Not only the recycling rate is low, and the waste is large, but it is also harmful to human health and the environment. Therefore, the scientific and effective recycling and utilization of aluminum ash is a top priority.



In recent years, the development of my country's aluminum industry has made considerable progress. At the same time, the output of aluminum ash has increased year by year. According to statistics, the amount of secondary aluminum ash produced in my country every year is about 1 million tons. With the levy of environmental protection taxes, enterprises urgently need new technologies for large-scale consumption of secondary aluminum ash. At present, secondary aluminum ash has become a great prospect for the green and healthy development of the aluminum industry.



The more common treatment method is to use various aluminum ash processing equipment, mainly aluminum ash ball mill, aluminum ash rotary kiln, aluminum ash flotation machine, aluminum ash separator, shaker and other equipment. For secondary recycling, it can be directly processed on site. The aluminum slag can be recycled through the aluminum ash separator. The recovery rate is high, and the effective recovery rate of aluminum can be as high as 90% or more. Secondly, the equipment is fully enclosed and does not pollute. Environment; through the recycling process, the secondary utilization of resources is realized and the problem of waste stacking is solved.



Treatment process of cold aluminum ash separator:

Cold aluminum ash separation: crushing→sieving

The cold ash separator is mainly based on the ash drawn from the factory, and the metal can be separated after being ground by a grinder and then passed through a separator. The grinder is equipped with two rollers to reduce the abrasion of aluminum particles. After grinding, the ash is ground into powder, and the aluminum will not be ground, and the shape becomes flakes. The grinder is equipped with a dust cover and connected by a pipe. The airflow is operated under negative pressure, and the airflow draws the dust generated during grinding into the dust collector for filtering and dust removal, and finally the clean air is discharged into the atmosphere.



The separator adopts the principle of air flow separation. The air volume generated by the fan circulates in the pipeline to drive the metal powder into the classifier. Because the ash is lighter than the metal powder, the ash is blown into the storage room and the metal powder falls into the vibrating screen for fineness classification. Since the fine aluminum powder is difficult to oxidize when smelting aluminum, it reduces the output. When smelting aluminum, it is necessary to add aluminum particles and aluminum powder in proportion to reduce the oxidation component of the fine aluminum powder, thereby increasing the output. The usual ratio is 3:2:1, so it is separated The machine screen is divided into two layers, 2 mm and 60 mesh. The fineness and number of layers can be adjusted according to the needs. The complete set of equipment includes: grinder, feeder, separator, powder collector, dust collector, silo conveyor The machine consists of several major parts.



Henan Zhengzhou Mining Machinery Co., Ltd. is a high-tech enterprise with full-process technology integrating scientific research, design, manufacturing, installation, commissioning, and guaranteeing operation. It has a complete set of aluminum ash disposal technology and equipment manufacturing.
