Introduction

Ball Mill with Sieve is a central drive and circumferential discharge mill. Due to the particularity of its internal structure, it has a grading effect while crushing and grinding materials. It has the characteristics of high efficiency, energy saving and environmental protection, and can be applied to abrasives, building materials, refractory materials, chemicals and other industries etc.

Features

1. Grinding and sieving are concentrated in one and can be completed at the same time;

2. The liner is made of high-quality wear-resistant material, which is wear-resistant and has a long service life;

3. The fineness of the product is fine and the particle size is uniform, the particle gradation is easy to adjust, and the product qualification rate is high;

4. Relatively low energy consumption, low operating cost, negative pressure operation, small dust pollution, and uniform discharge particle size;

5. The equipment has a simple structure, high grinding efficiency, and can avoid the phenomenon of excessive grinding and insufficient grinding of materials.

Technical Parameter

Specification（m）	Capacity（t/h）	Rotating speed（r/min）	Grinding body（t）	Motor		Reducer		Weight（t）
Specification（m）	Capacity（t/h）	Rotating speed（r/min）	Grinding body（t）	Model	Power（kw）	Model	Speed ratio	Weight（t）
Φ1.9×0.9	0.5～0.8	24.15	0.75	Y200L1-6	18.5	ZQ65-40	40.17	7.2
Φ2.1×1.0	0.8～1.05	24.15	0.9	Y200L2-6	22	ZQ65-40	40.17	9.5
Φ2.2×1.2	0.9～1.1	21.8	1.0	Y225M-6	30	ZL65-45	45	11.8

Wearing Parts：

No.	Name	Material	Qty.	Part	Remarks
1	End Liner	ZG65Mn	As required	Rotary device	Different specifications, different quantities
2	Liner	ZG65Mn	As required	Rotary device	Different specifications, different quantities
3	Screen	Q235	As required	Rotary device	Different specifications, different quantities
