Lithium Rotary Kiln

Inquiry

Introduction

Rotary kiln calcining lithium equipment uses lepidolite as raw material, and is carried out through mixing, roasting, cooling, crushing and other processes. Our company has been devoted to the research of lithium rotary kiln for many years, and has studied various common symptoms of the rotary kiln. It effectively solves the problems of calcium carbonate rotary kiln ring formation, low output and high energy consumption.

Application：

It is suitable for many production industries such as building materials, metallurgy, chemical industry, refractory materials, environmental protection and so on.

Features

1. The design of lithium rotary kiln fully considers the angle of the deflection support of the barrel to extend the life of refractory bricks and pouring;

2. The lithium rotary kiln adopts large diameter and small length-to-diameter ratio roller bearings to improve reliability, and the bearings are self-aligning bearings;

3. Lithium rotary kiln belongs to a new type of open gear cover sealing form with good sealing effect;

4. The spring sheet laminated flexible seal, and the double-layer spring sheet seal increases the design of the heat insulation layer, which helps to improve the reliability and service life of the lithium rotary kiln.

Technical Parameter

Model	Capacity（t/d）	Pedestal Qty. (Group)	Reducer	Motor	Power (kW)
Ø2.2×38m	120	2	ZS125-5	YVF₂-225M-4	45
Ø2.5×40m	150	2	ZS145-5	YVF₂-250M-4	55
Ø2.8×43m	200	2	ZS165-6	YVF₂-280S-4	75
Ø3.0×50m	230	2	ZS165-3	YVF₂-280M-4	90
Ø3.2×50m	250	2	ZL130-16	YVF₂-315L2-6	132
Ø3.6×55m	400	2	ZSY560-63	YVF₂-355M1-6	160
Ø3.8×58m	500	2	ZSY560-63	YVF₂-355M2-6	185
Ø4.0×60m	600	2	ZSY630-35.5	YVF₂-355M4-6	200
Ø4.3×64m	800	2	ZSY630-35.5	YVF₂-355L3-6	250
